CONTACTOR AC LT1-F150A 230V 1NO 23151

Technical characteristics: - Operation class: ??3 - Rated operating voltage of power contactors: up to 1000V;50/60Hz - Rated current: 115-800? - Surge voltage wear resistance: >8000V - Rated operating voltage of the coil: 12/24/36/48/110/230/400 - Electrical wear resistance (number of cycles): =10000000 - Mechanical wear resistance (number of cycles): =10000000 - Number of cycles (switching on) per hour: 200 - Power dissipation per pole: from 16 to 80W - Ambient temperature: -10ş ÷65ş? - Maximum altitude: up to 2000? Advantages: - High reliability of the current parameters - Secure separation of the power contacts - Resistant to UV rays - Easy mounting - Long life Functions: - Frequently switching ON/OFF of electrical circuits under load - Developing of systems for control of consumers - Operational element in control boards - Protection of loads and electrical devices in production and exploitation - Control of motors in normal or heavy operating environments Applications: - Industry - Building construction - Administrative and public buildings Mounting: On a DIN rail or using screws to a flat surface in a vertical position with maximum incline of ±5° Standards: EN60947-1; EN60947-4-1; EMC
