BEC LED GY6.35 3.3W 470LM 827K 12V CAPSULE CLEAR 12V AC/DC

Electrical data Nominal wattage 3.3 W Construction wattage 3.30 W Nominal voltage 12 V Operating mode 12V AC/DC Claimed equiv. conventional lamp power 40 W Nominal current 400 mA Type of current AC/DC Inrush current 19.7 A Max. lamp number on MCB B10 A 30 Max. lamp number on MCB B16 A 38 Total harmonic distortion < 120 % Power factor ? > 0.50 Photometrical data Luminous flux 470 lm Nominal useful luminous flux 90° 470 lm Luminous efficacy 142 lm/W Lumen main.fact.at end of nom.life time 0.93 Light color (designation) Warm White Color temperature 2700 K Color rendering index Ra 80 Light color 827 Standard deviation of color matching ?6 sdcm Flickering metric (Pst LM) 1.0 Stroboscope effect metric (SVM) 0.4 Light technical data Beam angle 320 ° Warm-up time (60 %) ‹ 0.50 s Starting time < 0.5 s Dimensions & Weight Overall length 43.00 mm Diameter 16.00 mm Maximum diameter 16 mm Product weight 6.5 g Temperatures & operating conditions Ambient temperature range -20…+40 °C Maximum temperature at tc test point 78.6 °C Lifespan Lifespan L70/B50 at 25 °C 15000 h Number of switching cycles 100000 Lumen maintenance at end of service lifetime 0.93 Additional product data Base (standard designation) GY6.35 Mercury content 0.0 mg Mercury-free Yes Design / version Clear Product remark All technical parameters apply to the entire lamp, Due to the complex production process for light-emitting diodes, the typical values shown for the technical LED parameters are purely statistical values that do not necessarily match the actual technical parameters of each individual product, which can vary from the typical value Capabilities Dimmable No
